telleasy
Main features:
- GPRS data transfer
- Built-in GPS receiver
- Web interface
- Connectable to car alarms
- Programmable through USB and IP
- FULL version functions:
- RPM monitoring from alternator star point
- RPM monitoring from alternator power terminals - using interface
- Data inputs: F1, F2, TEMP/RFID (fuel probes, temperature sensors, RFID reader)
- Outputs: POWER OUT, OUT1, OUT2, Speaker
- RFID proximity reader support for driver identification
- CAN Adapter support
Technical data:
- Transmission frequency: GSM 900/1800/850/1900 MHz
- Supply voltage: 10-28 VDC
- Current consumption:
- Nominal: 120mA
- Maximum: 500mA
- Standby: ≈20mA@12VDC
- Operating temperature: -20°C - +70°C
- Dimensions: 82 x 125 x 40mm
- GPS antenna dimensions: 50 x 38 x 17mm
- Weight: 200g
Characteristics of the system:
- Visualization and logging of position and route
- Separation of business/private vehicle usage
- Evaluation of speed, parking, trip duration, etc.
- Sends SMS with actual vehicle position and traffic data
Actions taken the effect of events:
- forwards car alarm signals to monitoring station
- sends SMS to the user’s phone
Independent alarm functions: position change monitoring at stopped engine, alarms triggered by contact inputs
Operational options:
- Web server service - www.easytrackmap.com
or
- Individual server for monitoring station
- Web-based visualization on Google Maps™ surface
- Private POI management, speed and fuel diagram, route report, vehicle uptime report, refueling report
- Low operational costs
Application area:
Vehicle tracking
Fleet management
